Basic Info.
Model NO.
VY171
Type
Convex Lens
Transmittance
>95%
Shape
Single-lens
Material
Optical Glass
Lenses Color
Clear
Certification
RoHS, ISO9001, CE
Customized
Customized
Coating
as Request
Tolerance
+/-0.01
Diameter
3-500
Surface Quality
10-5
Chamfer
0.1 X 45 Degree
Transport Package
as Request
Specification
as request
Trademark
VY or OEM
Origin
China
HS Code
9001909090
Production Capacity
500000
Packaging & Delivery
Package Size
0.50cm * 0.50cm * 0.50cm
Package Gross Weight
0.100kg
Product Description
Plano-Convex Lens is widely use in optical display systems, projection optics systems, imagining optical systems, and laser measurement systems. It is best use where conjugate point-- object distance, S or image distance S' is more than five times of the other. This lens is almost the most super form for both collimating a point source and focusing collimated light;
Plano-Concave Lens has a negative focal length and is typically used to cause a collimated beam to diverge as in a Galilean type beam expander or Telescope. Because the spherical aberration of the Plano-Concave is negative, it can be used to balance the aberration of other lenses.This lens is widely use in optical display systems, projection optics systems, imaging and laser measureemnt systerms;
Double-Convex Lens, also named Bi-Convex Lens, is most suitable where the object and image are on opposite sides of the lens and the ratio of the image and object (conjugate ratio) distances is between 0.2 to 5. It is used in beam expanders,. Projection optics systems, optical viewers etc;
Double-Concave Lens, also named Bi-Concave Lens, is used to divergent light. The Bi-Concave is best used when the input beam is converging. It is used in beam expanders,. Projection optics systems, optical viewers and optical charater readers etc;
Meniscus Lens can increase the NA of the system while only adding slightly to the total spherical aberrations. The Negative Meniscus Lens is used to increase the focal length of another lens while maintaining the angular resolution of the optical assembly. This lens shape is best used when one conjugate is relatively far from the lens.We supply optical spherical lenses,include plano-convex spherical lens,plano-concave spherical lens,bi-convex spherical lens,bi-concave spherical lens,meniscus spherical lens,special spherical lens etc..
Specification of our plano-convex spherical lenses as follow:
*Material:BK7 or other materials
*Focal length:+/-1%
*Center thickness tolerance:+/-0.01mm
*Centration:1 arc minutes
*Surface Figure:lambda/2 at 633nm on plano side
*Surface quality:40/20 stratch/dig
*Clear Apenture>90%
*Chamfer Protective:0.25mm at 45 degree typical
*Coating:optional
