Basic Info.
Model NO.
VM-500
Transport Package
Plywood
Specification
CE
Trademark
SINOWON
Origin
Dongguan
HS Code
90318020
Production Capacity
20 Sets/Month
Product Description
Auto Focus Video Microscope VM-500
Application:
Incoming inspection, production inspection, material research, PCB and SMT inspection analysis, printing, textile inspection, biological anatomy, medical testing and other fields.
Product Characteristics:
- Integral design, exquisite, fashion, generous;
- Built-in FULL HD sensor and VGA integrated camera, can directly connect with the monitor to realize video image and can also use SD card to take picture or record video, which integrate video observation and image storage;
- With high definition 0.7~4.5X parallel continue zoom lens, it is more convenient and fast to switch objective magnification;
- With adjustable LED surface reflection illumination, is able to control brightness independently;
- With 2 million pixel auto focus camera, no need to waste time for manual focus frequently.
Technical Specification:
| Product Name | Auto Focus Video Microscope |
| Model | VM-500 |
| Code# | 451-450 |
| Electronic Magnification | 33.47X~215.19X( HDMI 16:9 21.5"Monitor;) |
| Optical Objective | 0.7X~4.5X Zoom Lens |
| Zoom ratio:6.5:1 | |
| Camera Parameters | 2 million pixel (1920*1080) |
| Image Size:1/2.8" | |
| Frames Per Second:30fps | |
| Camera Function | Auto Focus |
| Cross Line | |
| Photograph and Video Record | |
| Output: HDMI | |
| White Balance; Brightness Control; Digital Noise Reduction | |
| Illumination | Surface: Adjustable LED Surface Illumination |
| Ring Fiber Illumination Optional | |
| Microscope Stand | Z-axis Travel: 100mm |
| Coarse Lifting System | |
| Electrical Parameters | AC90~240V;50~60HZ |
| Dimension | 310*285*500 mm |
| Weight | 6Kg |
Standard Delivery:
| Product Name | Specification |
| Microscope Main Body | VM-500 |
| Power Adapter | DC5V(Camera),DC12V(Illumination) |
| Monitor | Optional 4:3 21.5" |
| Operation Manual/Warranty Card/Certificate/Packing list | VM-500 |
